PTM – PRESSURE PROBE

  • High accuracy
  • Minimum energy demand
  • Parameterisation via SDI-12
  • long-term measurement stability
  • Solid, compact, aluminium housing
Add to quote
SKU: 991 Categories: ,


Description

PTM PRESSURE PROBE

The PTM– Pressure probe, measures water level and temperature. It offers long-term measurement stability with an extremely high accuracy of 0.05%. Using an SDI-12 interface (analog 4-20mA is optional) makes the integration simple and easy. With a robust stainless steel housing (titanium is optional) and a rugged cable, this sensor is ideal for monitoring water levels in a variety of applications.





Specifications

LEVEL MEASUREMENT

  • Measurement range 0 … 10m, 0 … 1bar
  • Accuracy 0.05% FS
  • Units mbar, bar, mWC, mH2O, psi, inWC, ft WC, inH2O

TEMPERATURE MEASUREMENT

  • Measurement range -25° C … +80° C
  • Accuracy ≤ ± 0.3 / ≤ ± 0.5 °C

GENERAL

  • Output SDI-12
  • Operating temperature -5° C … +80° C
  • Power supply 8 … 30 VDC
  • Dimensions Ø24 x 160 mm
  • Material Stainless steel (316L / 1.4404)
  • Cable length max. 250 m

PDF catalogue

Datenblatt_PTM-SDI-10_EN
